Freze de precizie,Scule de tăiere pentru prelucrarea CNC a fiecărui material
End Milling Cutters: Opțiuni de specificații
End milling cutters vary by cutter type and application. In addition to the general product options listed above, customers can select or customize the following dimensions and technical details according to the machining requirement.
| Caietul de sarcini | Opțiuni disponibile |
|---|---|
| Diametrul de tăiere | Dimensiuni standard metrice sau inci; diametre personalizate disponibile |
| Lungimea flautului | Standard, lung, or custom flute lengths according to cutting depth and application |
| Lungimea totală | Standard or extended lengths; custom overall lengths available |
| Dimensiunile tijei | Standard metric or inch shanks; redus, întărit, or custom shank dimensions available |
| Helix & Geometria marginilor | Standard or application-specific helix angles, core designs, pregătirea marginilor, and flute geometry |
| Toleranţă | Standard production tolerance or drawing-specified tolerance after technical review |
End milling cutters can involve many combinations of diameter, lungime, geometrie, toleranţă, și condițiile de prelucrare. Prin urmare, we confirm the final specifications according to the customer model, desen, eşantion, materialul piesei de prelucrat, aplicarea, si cantitate.
End Milling Cutters: Aplicații & Selecţie
Machinists use end milling cutters for slotting, buzunare, profilare, frezare laterală, frezarea umărului, conturarea, rough machining, finish machining, prelucrarea matrițelor și matrițelor, and general CNC component production.
Choose the cutter according to the machined feature, materialul piesei de prelucrat, diametrul tăietorului, adâncimea de tăiere, evacuare cip, surplusul sculei, rigiditatea mașinii, metoda lichidului de răcire, și finisarea necesară a suprafeței.
Select by End Geometry
Flat or square end mills are suitable for slots, buzunare, trepte, caracteristici cu fundul plat, și umerii pătrați. For dedicated flat-end options, vedea Moara plată.
Ball nose end mills are commonly used for curved surfaces, mucegaiuri, moare, and three-dimensional contouring. Vedea Freze cu cap bilă.
Corner radius or bull nose end mills combine a flat cutting area with a strengthened corner radius. Ca urmare, they suit applications where corner strength and a controlled radius are required. Vedea Taur Nose End Mill.
Tapered end mills suit angled walls, mucegaiuri, moare, and features that require a tapered tool body. Vedea Freză conică.
For a broader comparison of cutter geometries and their typical uses, citire Tipuri de freze de freza.
Selectați după materialul piesei de prelucrat
Aluminum and other non-ferrous materials require attention to chip evacuation, edge sharpness, spațiu pentru flaut, and reduced chip adhesion.
When machining carbon steel and alloy steel, match cutter rigidity, puterea muchiei, configurație flaut, calitate de carbură, and coating to the material hardness and cutting conditions.
Stainless steel requires a balanced combination of cutter geometry, puterea muchiei, acoperire, evacuare cip, and stable cutting conditions. For dedicated tooling options, vedea Freze pentru oțel inoxidabil.
Fontă, cupru, materiale plastice, grafit, compozite, and other materials may require different geometries, grades, or coatings. Prin urmare, customers can provide the exact material grade and machining requirement before tool selection.
Select by Flute Count
Două- and three-flute cutters provide more flute space. Prin urmare, they can support chip evacuation in applications where larger chips need to leave the cutting area efficiently.
patru-, cinci-, and six-flute cutters provide more cutting edges. în plus, they can suit applications where rigidity and finishing performance are more important.
Cu toate acestea, flute count should not be selected alone. Diametrul tăietorului, materialul piesei de prelucrat, adâncimea de tăiere, evacuare cip, rigiditatea mașinii, and machining operation should also be considered.
For more information about flute design and flute-count selection, citire Ghid pentru flaut moara de capăt.
End Milling Cutters: Caracteristici cheie
Solid Carbide and HSS Manufacturing
OMIST manufactures both solid carbide and HSS end mill cutters.
Carbura solidă oferă o rigiditate ridicată, rezistenta la uzura, și stabilitate dimensională. Prin urmare, manufacturers commonly use it for CNC milling where cutting performance and tool life are important.
HSS provides greater toughness and can suit selected general machining, lower-speed cutting, dimensiuni mai mari de tăietor, and special applications.
For dedicated solid carbide options, vedea Freză din carbură.
2–6 Flute Production
OMIST manufactures 2-, 3-, 4-, 5-, and 6-flute end milling cutters in standard and custom configurations.
Customers can select flute count, spațiu pentru flaut, unghiul helixului, diametrul miezului, and cutting-edge preparation according to chip evacuation, rigiditate, materialul piesei de prelucrat, și operațiunea de prelucrare.
Multiple Hardness and Coating Series
OMIST offers HRC45, HRC55, HRC60, and HRC65 series for different workpiece materials and machining conditions.
Coating options include AlTiN, TiAlN, TiSiN, Cositor, DLC, Nano Blue, and other application-specific coatings.
The workpiece material, duritate, temperatura de tăiere, metoda lichidului de răcire, and machining conditions determine the suitable hardness series and coating. Prin urmare, coating selection should not rely on the coating name alone.
Custom End Milling Cutter Manufacturing
OMIST provides custom end mill manufacturing when standard cutters cannot meet the required dimensions, ajunge, geometrie, profile, toleranţă, or machining conditions.
Customers can send a drawing, eşantion, lista de marimi, model de referință, desenul piesei, or application description for evaluation.
Custom manufacturing options include non-standard cutting diameter, lungimea flautului, lungime totală, dimensiunile tijei, număr de flaut, unghiul helixului, raza colțului, profilul final, cutting-edge geometry, acoperire, toleranţă, marcaj cu laser, customer model numbers, și ambalaj.
Înainte de producție, our team reviews the main tool dimensions, material pentru scule, materialul piesei de prelucrat, operatie de prelucrare, acoperire, toleranţă, cantitate, and other important requirements. We then confirm the final specification and manufacturability before quotation or production.
For projects focused specifically on non-standard tooling, vedea Freze la comandă.
End Milling Cutter FAQs
What types of end milling cutters do you manufacture?
We manufacture flat or square, nas de minge, corner radius or bull nose, degrosare, tapered, and other special-profile end mills. The appropriate geometry depends on the machined feature and application.
Are metric and inch end mill sizes available?
Da. We manufacture metric and inch specifications according to customer requirements. în plus, we can evaluate non-standard diameters, lungimi, tulpini, razele, si alte dimensiuni.
Can you manufacture end mills according to a drawing or sample?
Da. We can evaluate drawings, mostre, liste de dimensiuni, modele de referință, desene piese, and machining requirements before confirming the final cutter specification.
Can you help select an end mill for my workpiece and application?
Da. Vă rugăm să furnizați materialul piesei de prelucrat, operatie de prelucrare, cutter dimensions or part feature, condiţiile maşinii, and any known requirements. Based on this information, we can evaluate the suitable tool material, configurație flaut, geometria finală, hardness series, and coating before quotation.
Ce informații ar trebui să furnizez pentru o cotație?
Provide the information you already have, such as cutter diameter, număr de flaut, lungimea flautului, lungime totală, diametrul tijei, end geometry or radius, materialul piesei de prelucrat, operatie de prelucrare, acoperire, toleranţă, si cantitate.
Pentru instrumente personalizate, a drawing, eşantion, model de referință, or part drawing can help us confirm the specification more efficiently.
Do you support OEM and private-label orders?
Da. We support OEM production, marcaj cu laser, customer model numbers, neutral packaging, and private-label packaging according to the cutter specification, cantitate, and project requirements.
Send Your End Milling Cutters Inquiry
Send your end milling cutters inquiry by email, sau contactați-ne pe WhatsApp.
